F0JL24-S12RD000-01
Download page
JL24, Socket, 12Circuits, 90°Angle, Through Hole
Product System:
Product Category:
Status:
Active
Product Drawings
Product Specification
Category
Product Catalog
Connectors
Product System
Printed Circuit Connector
Product Category
JL24
Style
Socket
Pitch
2mm
Row Option
Dual row
Number of Positions
12Circuits
Orientation
Right angle(90°)
Colour
Green
Electrical
Current(Max)
1A
Voltage(Max)
300V
Contact Resistance
12.5 mΩ Max
Insulation Resistance
5000 MΩ Min
Withstanding Voltage
1000V AC r.m.s
Operating Temperature Range
-55ºC~+125ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Copper alloy
Plating
Gold plated
Plating Thickness
0.1μm
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
Tube
FAILED
The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
Quantity
Unit Price
1
$6.169404
10
$5.839156
50
$5.178661
100
$4.848414
500
$4.187920
1000
$3.350335
2500
$3.302474
5000
$3.254612
10000
$3.206750
25000
$3.158888
stock: 0 Estimated delivery date 2025-04-29
MPQ: 1
MOQ: 10
