F0JL23-P26SW000-01 JL23, Plug, 26Circuits, 180°Vertical, Soldering

F0JL23-P26SW000-01

Download page

JL23, Plug, 26Circuits, 180°Vertical, Soldering

Product Number：

F0JL23-P26SW000-01

Status：

Active

Data Download Product Introduction Compatible Parts

Category

Product Catalog

Connectors

Product System

Printed Circuit Connector

Product Category

JL23

Style

Plug

Pitch

2.54mm

Row Option

Dual row

Number of Positions

26Circuits

Orientation

Vertical(180°)

Colour

Green

Electrical

Current(Max)

Voltage(Max)

300V

Contact Resistance

10 mΩ Max

Insulation Resistance

5000 MΩ Min

Withstanding Voltage

1000V AC r.m.s

Operating Temperature Range

-55ºC~+125ºC

Mechanical

Mounting Style

Soldering

Material

Material-Contact

Copper alloy

Plating

Gold plated

Plating Thickness

0.1μm

Material-Resin

PA66

Flammability Rating

UL94 V-0

Packaging

Tube

Receptacle

F0JL23-S26RD000-01

JL23, Socket, 26Circuits, 90°Angle, Through Hole

F1JL23-S26SD000-01

JL23, Socket, 26Circuits, 180°Vertical, Through Hole

The pictures are for reference only for installation methods, please refer to the specifications and drawings for details

Quantity

Unit Price

$23.041009

10+

$21.830255

50+

$19.408748

100+

$18.197994

500+

$15.776487

stock 5 In stock

Immediate delivery is only the inventory quantity. If it exceeds the inventory quantity, you need to wait

MPQ： 1

MOQ： 10

When the purchase quantity is less than the inventory, you can purchase directly, and the minimum purchase quantity is 1

When the purchase quantity is greater than the inventory, you need to order; when ordering, the purchase quantity is: MOQ + N * MPQ
