FBB05003-F14S1003K6MH40 Board to Board 0.5mm, Female, 14Circuits, 180° Vertical(SMT)(H1=4mm)

FBB05003-F14S1003K6MH40

Download page

Board to Board 0.5mm, Female, 14Circuits, 180° Vertical(SMT)(H1=4mm)

Product Number：

FBB05003-F14S1003K6MH40

Status：

Active

Data Download Product Introduction Product Compliance Compatible Parts

Category

Product Catalog

Connectors

Product System

Board to Board Connector

Style

Socket

Gender

Female

Pitch

0.5mm

Row Option

Dual row

Number of Positions

14Circuits

Peg

Without peg

Height(mm)

Orientation

Vertical(180°)

Colour

Black

Electrical

Current(Max)

0.5A

Voltage(Max)

50V

Contact Resistance

40 mΩ Max

Insulation Resistance

100 MΩ Min

Withstanding Voltage

250V AC r.m.s

Operating Temperature Range

-25ºC~+85ºC

Mechanical

Mounting Style

SMT

Durability (Mating Cycles Max.)

Material

Material-Contact

Phosphor bronze

Plating

Gold plated

Plating Thickness

Gold flash

Material-Resin

PA9T

Flammability Rating

UL94 V-0

Packaging

Reel

REACH (EU REACH Regulation)	Does not contain REACH SVHC (1907/2006/EC)
ROHS (EU ROHS Directive)	Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2)
ELV (EU ELV Directive)	Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements

Plug

FBB05003-M14S1003K6MH10

Board to Board 0.5mm 180°Vertical(SMT) Male 14Circuits(H2=1mm)

FBB05003-M14S1003K6MH20

Board to Board Connector, 0.5mm, Male, 14Circuits, Vertical(180°), SMT, Without peg, H2,

The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
