FHG20009-S11M2W1B
Download page
Wire to board housing 2mm 180°Vertical 11Circuits(SAN)
Status:
Inactive
authentication:
REACH RoHS ELV
Product Drawings
Product Specification
Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Housing
Gender
Male
Pitch
2mm
Row Option
Single row
Number of Positions
11Circuits
Orientation
Vertical(180°)
Colour
White
Electrical
Current(Max)
2A
Voltage(Max)
250V
Operating Temperature Range
-25ºC~+85ºC
Material
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag
FAILED
The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
Quantity
Unit Price
1
$0.035531
10
$0.033126
50
$0.028315
100
$0.025910
500
$0.021100
1000
$0.012583
2500
$0.012412
5000
$0.012240
10000
$0.012069
25000
$0.011898
stock: 0 Estimated delivery date 2025-04-21
MPQ: 1000
MOQ: 1000
