FWF25401-S12S22W5B
Download page
Wafer 2.54mm 180°Vertical 12Circuits (DIP)
Status:
Active
authentication:
REACH RoHS ELV
Product Drawings
Product Specifications
Product Specification
Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
2.54mm
Row Option
Single row
Number of Positions
12Circuits
Orientation
Vertical(180°)
Colour
Natural
Electrical
Current(Max)
2.5A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1000V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag
FAILED
The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
Quantity
Unit Price
1
$0.106665
10
$0.099822
50
$0.086137
100
$0.079295
500
$0.065610
1000
$0.043395
2500
$0.042802
5000
$0.042210
10000
$0.041617
25000
$0.041025
stock: 0 Estimated delivery date 2025-04-22
MPQ: 500
MOQ: 1000
