FWF25404-S11S12K6B
Download page
Wafer 2.54mm 180°Vertical 11Circuits (DIP)
Status:
Inactive
authentication:
REACH RoHS ELV
Product Drawings
Product Specification
Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
2.54mm
Row Option
Single row
Number of Positions
11Circuits
Orientation
Vertical(180°)
Colour
Black
Electrical
Current(Max)
2.5A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
800V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Gold plated
Material-Resin
PBT
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag
FAILED
The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
Quantity
Unit Price
1
$0.284809
10
$0.267913
50
$0.234121
100
$0.217224
500
$0.183432
1000
$0.136290
2500
$0.134423
5000
$0.132556
10000
$0.130689
25000
$0.128822
stock: 0 Estimated delivery date 2025-04-21
MPQ: 500
MOQ: 1000
