FWF42006-S02S22TB
Download page
Wafer4.2mm 180°Vertical 2Circuits (DIP)
Status:
Active
authentication:
REACH RoHS ELV
Product Drawings
Product Specifications
Product Specification
Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
4.2mm
Row Option
Single row
Number of Positions
2Circuits
Orientation
Vertical(180°)
Colour
Clear
Electrical
Current(Max)
9A
Voltage(Max)
250V
Contact Resistance
15 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA66
Flammability Rating
UL94 V-2
Packaging
Packaging
PE Bag
FAILED
The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
Quantity
Unit Price
1
$0.132819
10
$0.124299
50
$0.107259
100
$0.098739
500
$0.081698
1000
$0.054035
2500
$0.053297
5000
$0.052560
10000
$0.051822
25000
$0.051084
stock 140 In stock
MPQ: 1000
MOQ: 1000
