FFH25413-D14B1014K6K

Download page

Female Header 2.54mm, Double row, 14Circuits, 90° Angle(DIP), 1μ", PA6T

Product Number：

FFH25413-D14B1014K6K

Status：

Active

Data Download Product Introduction Product Compliance Compatible Parts

{{item.nameEn}}

{{file.fileName}}

Category

Product Catalog

Connectors

Product System

Pin Header/Female Header

Product Category

Female Header

Style

Socket

Pitch

2.54mm

Row Option

Dual row

Number of Positions

14Circuits

Orientation

Right angle(90°)

Colour

Black

Electrical

Current(Max)

3A

Voltage(Max)

250V

Contact Resistance

20 mΩ Max

Insulation Resistance

1000 MΩ Min

Withstanding Voltage

500V AC r.m.s

Operating Temperature Range

-40ºC~+105ºC

Mechanical

Mounting Style

Through hole

Material

Material-Contact

Brass

Plating

Gold plated

Plating Thickness

0.025μm

Material-Resin

PA6T

Flammability Rating

UL94 V-0

Packaging

Packaging

Tray

REACH (EU REACH Regulation)	Does not contain REACH SVHC (1907/2006/EC)
ROHS (EU ROHS Directive)	Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2)
ELV (EU ELV Directive)	Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements

Receptacle

FBH25401-D14S1004K6K

Box Header 2.54mm 180°Vertical 14Circuits(DIP)

FBH25401-D14S1014K6K

Box Header 2.54mm 180°Vertical 14Circuits(DIP)(1μ'')

FBH25402-D14B1004K6K

Box Header 2.54mm 90°Angle 14Circuits(DIP)

FBH25402-D14B1014K6K

Box Header 2.54mm, 14Circuits, 90° Angle(DIP), 1μ", PA9T

FBH25403-D14S1004K6K

Box Header 2.54mm 180°Vertical 14Circuits(SMT)

FBH25403-D14S1004K6M

Box Header 2.54mm, 14Circuits, 180° Vertical(SMT), PA9T

FBH25422-D14S1014K6M

Box Header, 2.54mm, 14Circuits, Vertical(180°), SMT, PA9T

FBH25423-D14S1015K6B02

Box Header, 2.54mm, 14Circuits, Vertical(180°), Through hole, PA9T

The pictures are for reference only for installation methods, please refer to the specifications and drawings for details

Quantity

Unit Price

1+

$0.297581

10+

$0.280658

50+

$0.246810

100+

$0.229887

500+

$0.196040
